华为MTS9000A,室外机柜,MTS9304A-HD20A1,户外机柜，室外一体化通信电源柜，户外一体化机柜 MTS9000/9300A系列室外电源产品可应用于网络传输站点、接入站点和无线通信站点；该产品解决方案主要应用于市电良好区域，为各类负载设备提供高可靠的各种制式电源，应对复杂多变的应用场景。 通过统一平台的一体化设计、在业界率先通过数字化、网络化、智能化手段实现站点转型；以其简单、高效、可靠的智能特性帮助客户实现网络简单部署、全网节能、高效运维和未来平滑演进，最大限度节省客户部署及运维开支，保障站点可靠运行。 华为MTS9000A,室外机柜,MTS9304A-HD20A1,户外机柜，室外一体化通信电源柜，户外一体化机柜 MTS9000/9300A系列室外电源产品可应用于网络传输站点、接入站点和无线通信站点；该产品解决方案主要应用于市电良好区域，为各类负载设备提供高可靠的各种制式电源，应对复杂多变的应用场景。 通过统一平台的一体化设计、在业界率先通过数字化、网络化、智能化手段实现站点转型；以其简单、高效、可靠的智能特性帮助客户实现网络简单部署、全网节能、高效运维和未来平滑演进，最大限度节省客户部署及运维开支，保障站点可靠运行。 华为MTS9000A,室外机柜,MTS9304A-HD20A1,户外机柜
华为MTS9000A,室外机柜,MTS9304A-HD20A1,户外机柜 站址获取简单：将常规需占地10+平方米的室内站点减小到仅1平方米（单柜），平均节省30%站址成本。 电力获取简单：叠光改造，考虑遮阳棚+应急发电ROI<3年。 扩容简单：储能系统利旧现网电池模块化扩容（锂电直接混搭），节省电池合路器投资$500。 华为MTS9000A,室外机柜,MTS9304A-HD20A1,户外机柜 SEE（站点效率）最高可达95%，相比80%普通站点每年可节省电费690+USD。 搭载业界效率领先的98%超高效50A整流模块，55℃不降额，支持模块休眠、高效优先工作，相比现网90%模块每年可节省电费150+USD。 MTS9304A-HD20A1 电源模块85~300V超宽工作电压范围，500V耐高压，适应各类恶劣电网场景； 智能电池单体管理，SOC/SOH检测，运维成本节省￥600+/年/站； 支持锂电储能系统软件锁功能，减少电池偷盗损失$500/年/站； 支持电子门锁和视频监控，站点被盗率降低~8%，合~$150/年/站。 MTS9304A-HD20A1 技术规格 |
产品型号 | MTS9000A系列设备柜 | MTS9000A系列电池柜 | MTS9300A系列分体柜 |
尺寸(宽× 深 × 高) | 750mm ×750mm × 2030mm | 815mm × 735mm × 2030mm | 650mm × 650mm × 1000mm |
重量 | 150kg~192kg | 158kg~160kg | 55kg~85kg |
温控方式 | 热交换/空热一体/直通风/空调（可选） | TEC/空调（可选） | 热交换/直通风/直流空调（可选） |
用户空间 | 40U | 40U | 7~15U |
柜体材质 | 隔热夹芯板（适用于极端高低温区域） | 隔热夹芯板（适用于极端高低温区域） | 单层钢机柜（适用于常温区域） |
传感器（选配） | 烟感、水浸、门磁、环境温湿度 | 烟感、水浸、门磁、环境温湿度 | 烟感、水浸、门磁、环境温湿度 |
防护等级 | IP55(直通风IP45) | IP55 | IP55(直通风IP34) |
工作温度范围 | -40˚C ～+45˚C (热交换&直通风) | －40～+50℃+太阳辐射（TEC) | －10～+45℃+太阳辐射. |
工作海拔范围 | -60～4000m（2000～4000m时，高温降额，每升高200m降低1℃） | -60～4000m（2000～4000m时，高温降额，每升高200m降低1℃） | 0~4000m（2000～4000m时，高温降额，每升高200m降低1℃） |
智能特性（可选） | 储能SOH 管理 | 储能SOH 管理 | 储能SOH 管理 |
Huawei outdoor integrated cabinet, Huawei 5g communication power supply, Huawei mts9000a / mts9300a
Detailed introduction
Mts9000 / 9300A series outdoor power supply products can be applied to network transmission station, access station and wireless communication station; the product solution is mainly used in good areas of city power supply, providing various high reliable power supply for various load equipment and coping with complex and changeable application fields. Through the integrated design of the unified platform, we take the lead in the industry to achieve site transformation through digital, networking and intelligent means; with its simple, efficient and reliable intelligent features, we help customers achieve simple network deployment, energy saving, efficient operation and maintenance, and smooth evolution in the future, so as to maximize the cost of customer deployment and operation and maintenance, and ensure the reliable operation of the site.
simple
The station location is easy to obtain: the indoor station with 10 + square meters of floor space is reduced to only 1 square meter (single cabinet), and the site cost is saved by 30% on average. Power acquisition is simple: fold light reconstruction, considering sunshade + emergency power generation ROI < 3 years. Simple expansion: the energy storage system can expand the capacity of the existing network battery module (lithium battery direct mixing), saving the battery combiner investment of $500.
High efficiency
The highest see (site efficiency) can reach 95%, which can save 690 + USD per year compared with 80% ordinary stations. Equipped with 98% ultra efficient 50A rectifier module with industry leading efficiency, no derating at 55 ℃, supporting module dormancy, high efficiency and priority work, saving electricity cost of 150 + USD per year compared with 90% module in current network.
simple
Power module 85 ~ 300V ultra wide working voltage range, 500V high voltage resistance, suitable for all kinds of harsh power grid scenarios; smart battery monomer management, SoC / SOH detection, operation and maintenance cost savings of ￥ 600 + / year / station; support lithium battery storage system software lock function, reduce battery theft loss of $500 / year / station; support electronic door lock and video monitoring, site theft rate reduced by ~ 8%, totaling ~ $150 / year / station.
technical specifications
Product model: mts9000a series equipment cabinet mts9000a series battery cabinet mts9300a series split cabinet
Size (width × depth × height) 815mm × 735mm × 2030mm
(including base 150 mm) 815 mm × 735 mm × 2030 mm
(including base 150 mm) 650mm × 650mm × 1000mm
(including base 100 mm)
Weight: 150kg ~ 192kg
158kg~160kg 55kg~85kg
Temperature control mode: heat exchange / air heating integration / direct air / air conditioning (optional) Tec / air conditioning (optional) heat exchange / direct air / DC air conditioning (optional)
User space 40u 40u 7 ~ 15u
Cabinet material: heat insulation sandwich panel (applicable to extreme high and low temperature areas) heat insulation sandwich panel (applicable to extreme high and low temperature areas) single layer steel cabinet (applicable to normal temperature area)
Sensors (optional) smoke sensing, water immersion, door magnetism, ambient temperature and humidity smoke sensing, water immersion, door magnetism, ambient temperature and humidity, smoke sensing, water immersion, door magnetism, ambient temperature and humidity
Protection grade: IP55 (through wind IP45) IP55 (through wind ip34)
Operating temperature range - 40 ℃ C to + 45 ℃ C (heat exchange & through air)
-40 ℃～ + 55 ℃ C (air heat integration) - 40 ℃～ + 50 ℃ + solar radiation (TEC)
- 40 ～ + 55 ℃ + solar radiation (air conditioning) - 10 ～ + 45 ℃ + solar radiation
Working altitude range - 60-4000m (when 2000-4000m, high temperature derating, 1 ℃ for every 200m increase) - 60-4000m (for 2000-4000m, high temperature derating, 1 ℃ for every 200m increase) 0-4000m (for 2000-4000m, high temperature derating, 1 ℃ for every 200m increase)
Intelligent (optional) energy storage SOH management
Site energy efficiency management
Image capture
access control
Mobile app management and energy storage SOH management
Access control management and energy storage SOH management
Site energy efficiency management
access control
Mobile app management
